KP-5 / KP-5.5 containers
Open KP-5.5 container
- Capacity
- 5,5 m³
- Floor / side walls
- 3 mm / 2,5 mm
A compact universal container
Open KP-5 and KP-5.5 containers
A container for rubble, construction waste and mixed waste. The universal version is compatible with both 1200 mm hooklift equipment and skip loader systems.
Capacity5–5,5 m³
Payload10 000 kg
System / standard1200 mm hook / skip loader
Product gallery
Technical data
Design specifications
These specifications describe a typical version. Dimensions, material thicknesses and equipment can be tailored to your order.
- Internal length
- 3350 mm
- Internal width
- 1600 mm
- Internal height
- 1000 mm
- Floor thickness
- 3 mm
- Side wall thickness
- 2,5 mm
- Runner spacing
- 1020 mm
Product documentation
Find a data sheet
Select the capacity and plate thicknesses, then download the PDF.
Data sheets found: 1 of 1
No data sheets match these parameters. Change your criteria or clear the filters.
PDF files are provided in their original language.
